We used the laser to align the degrader (see attached photos)

According to the LISE calculation, equivalent effective thickness for 6 mm of Carbon target is 4.5 mm thick Aluminum.

Therefore, we&#39;ve set the degrader system as follow:

<div>
<table>
	<tbody>
		<tr>
			<td>
			No
			</td>
			<td>
			Thickness
			</td>
			<td>
			Center Position(maybe a little shift)
			</td>
			<td>
			Remove Position(maybe a little shift)
			</td>
		</tr>
		<tr>
			<td>
			1
			</td>
			<td>
			2.2 mm
			</td>
			<td>
			+ Maximum(+ 99676)
			</td>
			<td>
			Home (0)
			</td>
		</tr>
		<tr>
			<td>
			2
			</td>
			<td>
			1.0 mm
			</td>
			<td>
			+ Maximum(+ 85042)
			</td>
			<td>
			Home (0)
			</td>
		</tr>
		<tr>
			<td>
			3
			</td>
			<td>
			2.2 mm
			</td>
			<td>
			+ Maximum(+ 84962)
			</td>
			<td>
			Home (0)
			</td>
		</tr>
		<tr>
			<td>
			&nbsp;

Control PC IP:10.32.6.153

user: decay

password: d******8

Click Logitec ?<a class="nonexistent" href="http://ribf-exp.riken.jp/ribfwiki/QuickCam">?</a>QuickCam and SEGEMCS to view the camera
			</td>
			<td>&nbsp;</td>
			<td>&nbsp;</td>
			<td>&nbsp;</td>
		</tr>
	</tbody>
</table>
</div>
