Entry time:
Wed Feb 14 08:44:32 2024
Author
*
:
Subject
*
:
<p>Run number changed 09:44 - Now run 23</p> <p>Moving motors with the injection</p> <p>Ring signal very weird, moving in for short time and staying out for 15+ seconds.</p> <p> </p> <p>R24</p> <p>Right arm FULLY in (70.49 mm)</p> <p>Left arm SERVOS ONLY in (36.54)</p> <p>No appreciable effect on beam (not clipping beam at injection / during circulation)</p> <p> </p> <p>ML fixed signal cycle. It's now 8 seconds in, 5 seconds out. Motors still not moving. Acquiring more stats in the current conditions.</p> <p> </p> <p>11:07 - Temps & System wide checks good</p> <p>Stats as before.</p> <p>Leakage currents & pressure good.</p> <p>11:44</p> <p>Leakage current ok. pressure good. Temperatures ok. Merger ok. System wide checks ok.</p> <p>In with the left 36.5</p> <p>In with the right 70.5</p> <p>Attatchment 1: Rates</p> <p>Attatchment 2: Temperatures</p> <p>Attatchment 3: Waveforms layout 7</p> <p>Attatchment 4: Waveforms layout 8</p> <p>Attatchment 5: Waveforms layout 1</p> <p>Attatchment 6: Waveforms layout 2</p> <p>Attatchment 7: Leakage current</p> <p>Attatchment 8: lowenergyXYtotal all 4 dets</p> <p>Attatchment 9: lowenergyExEy all dets</p> <p>Attatchment 10: loveenergyvExEy</p> <p>Attachment 11: screenshot from the Shottky</p> <p> </p> <p>14:00 Run 24 stopped to allow access to the cave.</p> <p>Helium and liquid nitrogen re-filled in the target.</p> <p>Pulser walkthrough performed R25.</p> <p>Turned CARME turbo ON, pressure in the ring with target on is reduced by a factor 2.</p> <p>Tried to find electron cooler voltages to determine the beam energy. We were unable to do this. Hopefully we find out tomorrow. </p> <p> </p>
Encoding
:
HTML
ELCode
plain
Suppress Email notification
Resubmit as new entry
Attachment 1:
Original size: 3840x1080
Attachment 2:
Original size: 3840x1080
Attachment 3:
Original size: 3840x1080
Attachment 4:
Original size: 3840x1080
Attachment 5:
Original size: 3840x1080
Attachment 6:
Original size: 3840x1080
Attachment 7:
Original size: 3840x1080
Attachment 8:
Original size: 3840x1080
Attachment 9:
Original size: 3840x1080
Attachment 10:
Original size: 3840x1080
Attachment 11:
Original size: 1920x1080
