Entry time:
Thu Jun 5 16:54:18 2025
Author
*
:
Subject
*
:
<p>Run 52 started at 17:53. Everything is running again. We started at 3E12 at/cm2</p> <p>D+ beam deuterium target. D+ beam energy is now 0.3 MeV/u. (beam calc calculation is 0.3067 MeV/u).</p> <p>All four detectors positioned fully out and stationary and also detector #4 is running again.</p> <p>Left potentiometer = -3.03mm (corresponds to x = 0, which is the more trustworthy value)</p> <p>Right potentiometer = 1.82 mm (corresponds to y = -1000, which is the more trustworthy value)</p> <p>Ring cycle time is 5 seconds.</p> <p>Cooler set value = 177.9 V, 4 mA. Read value = 177.65 V, 3.53 mA</p> <p>All leakage currents look good.</p> <p>Beam position. Vertical =0.0mm , Horizontal=1.0 mm</p> <p>Data rate ~ 947kB/s<br /> <br /> 18:09: System check - everything perfect!</p> <p>Leakage current attachment 1</p> <p>Rates attachment 2<br /> <br /> 19:50: System check - everything marvelous!</p> <p>22:05: System check - everything excellent!</p> <p>22:50: System check - everything fabulous!</p> <p>current spectra attachment 3</p> <p> </p> <p>02:05</p> <p>Temperatures OK</p> <p>System wide checks OK</p> <p>Statistics OK</p> <p>Merger OK</p> <p>Leakage current OK</p> <p>Ring vacuum OK</p> <p> </p> <p>04:52</p> <p>Temps OK</p> <p>System wide checks OK</p> <p>Stats OK - attached</p> <p>Merger OK - attached</p> <p>Leakage OK - attached</p> <p>Histos look good - attached</p> <p> </p> <p>07:10</p> <p>Temps OK</p> <p>System wide checks OK</p> <p>Stats OK - attached</p> <p>Merger OK - attached</p> <p>Leakage OK - attached</p> <p>Histos look good - attached</p> <p> </p> <p>11:31</p> <p>All checks OK</p> <p>13:54</p> <p>All checks OK</p> <p>Rates attached</p> <p> </p> <p> </p> <p> </p> <p> </p>
Encoding
:
HTML
ELCode
plain
Suppress Email notification
Resubmit as new entry
Attachment 1:
Original size: 1920x1080
Attachment 2:
Original size: 1920x1080
Attachment 3:
Original size: 1920x1080
Attachment 4:
Original size: 1920x1080
Attachment 5:
Original size: 1920x1080
Attachment 6:
Original size: 1920x1080
Attachment 7:
Original size: 1920x1080
Attachment 8:
Original size: 1920x1014
Attachment 9:
Original size: 1920x1014
Attachment 10:
Original size: 1920x1014
Attachment 11:
Original size: 1920x1014
Attachment 12:
Original size: 1920x1014
Attachment 13:
Original size: 1920x1014
Attachment 14:
Original size: 284x841
