<p>Connected the flange with the cooling system in place, attached pictures represent the set up used. Currently testing for potential leaks as minimum pressure achived is 4.0e-5 mbar</p>

<table border="1" cellpadding="1" cellspacing="1" style="height:456px; width:594px">
	<thead>
		<tr>
			<th scope="col">Pressure (mbar)</th>
			<th scope="col">Time (sec)</th>
		</tr>
	</thead>
	<tbody>
		<tr>
			<td>8.7e-4</td>
			<td>109</td>
		</tr>
		<tr>
			<td>6.3e-4</td>
			<td>125</td>
		</tr>
		<tr>
			<td>4.5e-4</td>
			<td>155</td>
		</tr>
		<tr>
			<td>3.5e-4</td>
			<td>190</td>
		</tr>
		<tr>
			<td>1.2e-4</td>
			<td>430</td>
		</tr>
		<tr>
			<td>9.6e-5</td>
			<td>570</td>
		</tr>
		<tr>
			<td>8.1e-5</td>
			<td>720</td>
		</tr>
		<tr>
			<td>6.2e-5</td>
			<td>1030</td>
		</tr>
		<tr>
			<td>
			<p>5.8e-5</p>
			</td>
			<td>1200</td>
		</tr>
		<tr>
			<td>5.6e-5</td>
			<td>1500</td>
		</tr>
		<tr>
			<td>5.4e-5</td>
			<td>1680</td>
		</tr>
		<tr>
			<td>5.1e-5</td>
			<td>1930</td>
		</tr>
		<tr>
			<td>4.8e-5</td>
			<td>2340</td>
		</tr>
		<tr>
			<td>4.4e-5</td>
			<td>3120</td>
		</tr>
		<tr>
			<td>4.2e-5</td>
			<td>4200</td>
		</tr>
		<tr>
			<td>4.1e-5</td>
			<td>4860</td>
		</tr>
		<tr>
			<td>4.0e-5</td>
			<td>6480</td>
		</tr>
	</tbody>
</table>
