08.31 DAQ continues OK - file R33_263 ASIC settings 2019Dec19-16.19.51 DSSSD#1 slow comparator 0xa DSSSD#2 slow comparator 0xa DSSSD#3 slow comparator 0xd BNC PB-5 Pulser Amplitude1.0V Attenuation x1 Frequency 2Hz tau_d 1ms - polarity Delay 250ns, tail pulse 08.32 No merger server error/warning messages since most recent restart c. 00.00 today 08.44 System wide checks FEE64 module aida09 global clocks failed, 6 Clock status test result: Passed 11, Failed 1 Understand status as follows Status bit 3 : firmware PLL that creates clocks from external clock not locked Status bit 2 : always logic '1' Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock If all these bits are not set then the operation of the firmware is unreliable FEE64 module aida07 failed FEE64 module aida10 failed Calibration test result: Passed 10, Failed 2 If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module Base Current Difference aida05 fault 0x7a56 : 0x7a58 : 2 aida06 fault 0x65bb : 0x65bd : 2 aida07 fault 0xcdd1 : 0xcdd4 : 3 aida08 fault 0x2ab3 : 0x2ab5 : 2 White Rabbit error counter test result: Passed 8, Failed 4 Understand the status reports as follows:- Status bit 3 : White Rabbit decoder detected an error in the received data Status bit 2 : Firmware registered WR error, no reload of Timestamp Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR FPGA Timestamp error counter test result: Passed 12, Failed 0 If any of these counts are reported as in error The ASIC readout system has detected a timeslip. That is the timestamp read from the time FIFO is not younger than the last Returned 0 0 0 0 0 0 0 0 0 0 0 0 Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k aida01 : 14 6 3 2 1 2 2 3 3 4 11 : 58904 aida02 : 6 4 1 1 1 2 2 4 2 3 7 : 39848 aida03 : 5 6 4 2 1 3 1 3 2 3 7 : 39300 aida04 : 4 1 2 2 3 3 2 4 1 4 15 : 73912 aida05 : 1 5 2 2 2 4 2 3 2 3 7 : 39692 aida06 : 7 2 2 3 1 3 3 3 2 4 7 : 41836 aida07 : 6 3 1 2 3 2 2 3 3 3 7 : 40512 aida08 : 8 5 2 2 1 3 1 3 2 3 7 : 39272 aida09 : 1 2 3 1 1 3 2 3 1 4 7 : 40484 aida10 : 2 6 3 2 1 2 2 2 3 3 7 : 39912 aida11 : 2 3 1 0 2 4 1 3 2 3 7 : 39344 aida12 : 2 3 4 2 0 3 3 3 2 3 7 : 39712 FEE64 Temperatures OK - attachment 1 Good event statistics OK - attachment 2 Detector bias & leakage currents OK - attachment 3 Merger OK - 5.1M data items/s TapeServer OK - 16Mb/s 08.54 p+n junction strip HEC spectra - attachment 1 Rate spectra - attachment 2 09.15 Burst of Merger server warning messages of type MERGE Data Link (3547): bad timestamp 1 3 0x8128d6c8 0x05056328 0x00008d6c85056328 0x166b8d6c85056328 0x166b8d6d86da01ee also multiple Warning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: At least one MIDAS block missed in relayWarning: A The latter may reflect downstream problems writing MBS data
