Entry time:
Mon Apr 19 16:58:29 2021
Author
*
:
Subject
*
:
System Checks @ ~18:10 : FEE64 module aida09 global clocks failed, 6 Clock status test result: Passed 11, Failed 1 Understand status as follows Status bit 3 : firmware PLL that creates clocks from external clock not locked Status bit 2 : always logic '1' Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock If all these bits are not set then the operation of the firmware is unreliable FEE64 module aida07 failed FEE64 module aida09 failed Calibration test result: Passed 10, Failed 2 If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module Base Current Difference aida07 fault 0xd052 : 0xd05a : 8 White Rabbit error counter test result: Passed 11, Failed 1 Understand the status reports as follows:- Status bit 3 : White Rabbit decoder detected an error in the received data Status bit 2 : Firmware registered WR error, no reload of Timestamp Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR Base Current Difference aida12 fault 0x0 : 0x23 : 35 FPGA Timestamp error counter test result: Passed 11, Failed 1 If any of these counts are reported as in error The ASIC readout system has detected a timeslip. That is the timestamp read from the time FIFO is not younger than the last Returned 0 0 0 0 0 0 0 0 0 0 0 0 Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k aida01 : 1 6 4 0 1 5 2 3 2 3 6 : 35636 aida02 : 27 3 2 0 2 3 2 3 3 3 6 : 36516 aida03 : 33 9 2 1 1 3 2 3 3 3 6 : 36556 aida04 : 11 6 5 4 2 4 3 3 3 3 6 : 37036 aida05 : 15 8 7 4 3 4 4 2 3 3 6 : 36908 aida06 : 13 9 7 3 3 4 2 3 3 3 6 : 36876 aida07 : 1 3 3 2 2 3 1 3 3 3 6 : 36236 aida08 : 29 5 2 1 1 2 2 3 3 3 6 : 36380 aida09 : 3 8 2 0 2 3 2 2 2 4 6 : 36972 aida10 : 9 5 3 3 1 4 2 4 2 3 6 : 36124 aida11 : 5 7 3 2 2 2 2 4 2 3 6 : 35900 aida12 : 24 6 3 1 2 3 2 2 3 3 6 : 36064 System Checks @ ~19:55 FEE64 module aida09 global clocks failed, 6 Clock status test result: Passed 11, Failed 1 Understand status as follows Status bit 3 : firmware PLL that creates clocks from external clock not locked Status bit 2 : always logic '1' Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock If all these bits are not set then the operation of the firmware is unreliable FEE64 module aida07 failed FEE64 module aida09 failed Calibration test result: Passed 10, Failed 2 If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module Base Current Difference aida05 fault 0xdb9a : 0xdb9d : 3 aida06 fault 0xb74f : 0xb752 : 3 aida07 fault 0xd052 : 0xd05e : 12 aida08 fault 0xe4c1 : 0xe4c4 : 3 aida09 fault 0xaf4b : 0xaf4d : 2 White Rabbit error counter test result: Passed 7, Failed 5 Understand the status reports as follows:- Status bit 3 : White Rabbit decoder detected an error in the received data Status bit 2 : Firmware registered WR error, no reload of Timestamp Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR Base Current Difference aida12 fault 0x0 : 0x27 : 39 FPGA Timestamp error counter test result: Passed 11, Failed 1 If any of these counts are reported as in error The ASIC readout system has detected a timeslip. That is the timestamp read from the time FIFO is not younger than the last Returned 0 0 0 0 0 0 0 0 0 0 0 0 Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k aida01 : 18 10 2 2 1 5 2 3 2 3 6 : 35768 aida02 : 21 9 2 1 2 2 2 3 3 3 6 : 36444 aida03 : 13 5 6 1 2 2 2 3 3 3 6 : 36444 aida04 : 30 11 4 3 2 4 3 3 3 3 6 : 37104 aida05 : 10 9 8 4 4 4 4 2 3 3 6 : 36976 aida06 : 22 17 10 3 2 3 1 4 3 3 6 : 37088 aida07 : 20 8 4 1 2 4 1 2 3 3 6 : 35952 aida08 : 14 4 3 0 1 2 2 3 3 3 6 : 36296 aida09 : 24 8 4 0 1 3 3 3 3 3 6 : 36768 aida10 : 19 8 4 1 1 4 2 3 3 3 6 : 36652 aida11 : 6 6 1 2 3 1 2 4 2 3 6 : 35800 aida12 : 15 7 1 1 2 4 1 2 3 3 6 : 35876
