Entry time:

Wed Apr 21 23:05:39 2021

Author*:

Subject*:

00:07 stats/ucesb/DB checks all ok

00:30 all system wide checks ok *except* fpga errors

Base 		Current 		Difference
aida12 fault 	 0x0 : 	 0x1f : 	 31
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

statistics ok - attachment 1

temperatures ok - attachment 2

detector bias / leakage currents ok - attachment 3

no error messages in DB terminal & ucesb ok - attachment 4

01:00 stats/ucesb/DB checks all ok

01:30 stats/ucesb/DB checks all ok

01:53 issues with beam dropping in and out - ESR working to stabilise this

02:00 stats/ucesb/DB checks all ok

02:09 beam back in a stable state

02:30 all system wide checks ok *except* fpga errors

Base 		Current 		Difference
aida12 fault 	 0x0 : 	 0x29 : 	 41
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

02:33 statistics ok - attachment 5

temperatures ok - attachment 6

detector bias / leakage currents ok - attachment 7

no error messages in DB terminal & ucesb ok - attachment 8

02:45 beam off - potentially serious issue, awaiting update from FRS

03:00 significant issues with UNILAC, beam not expected back for a while

03:05 stats/ucesb/DB checks all ok

03:32 stats/ucesb/DB checks all ok

03:55 beam is back

04:00 stats/ucesb/DB checks all ok

04:30 all system wide checks ok *except* fpga errors

Base 		Current 		Difference
aida12 fault 	 0x0 : 	 0x2b : 	 43
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

04:32 statistics ok - attachment 9

temperatures ok - attachment 10

detector bias / leakage currents ok - attachment 11

no error messages in DB terminal & ucesb ok - attachment 12

05:00 stats/ucesb/DB checks all ok

05:30 stats/ucesb/DB checks all ok

06:00 stats/ucesb/DB checks all ok

06:30 all system wide checks ok *except* fpga errors

Base 		Current 		Difference
aida12 fault 	 0x0 : 	 0x34 : 	 52
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

06:32 temperatures ok - attachment 13

statistics ok - attachment 14

detector bias / leakage currents ok - attachment 15

no error messages in DB terminal & ucesb ok - attachment 16

07:00 stats/ucesb/DB checks all ok

07:30 stats/ucesb/DB checks all ok

07:59 stats/ucesb/DB checks all ok
