system wide checks:
Clock status:
FEE64 module aida06 global clocks failed, 6
Clock status test result: Passed 11, Failed 1
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
ADC calibration:
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida12 failed
Calibration test result: Passed 9, Failed 3
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
White Rabbit
Base Current Difference
aida06 fault 0x679f : 0x67a4 : 5
White Rabbit error counter test result: Passed 11, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
FPGA timestamp error page not working !!
Memory information:
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 19 15 4 6 4 3 2 4 2 3 6 : 36420
aida02 : 36 25 24 6 0 4 2 3 2 3 4 : 28056
aida03 : 17 7 4 3 3 5 2 2 3 3 6 : 36444
aida04 : 4 5 4 5 3 4 2 3 3 3 6 : 36824
aida05 : 23 9 4 2 3 3 1 3 3 3 6 : 36452
aida06 : 26 8 5 1 3 4 2 2 3 3 6 : 36312
aida07 : 21 9 3 3 4 5 1 2 3 3 6 : 36268
aida08 : 27 9 2 2 2 4 1 3 3 3 6 : 36500
aida09 : 13 4 3 3 1 2 4 2 3 3 6 : 36388
aida10 : 1 10 0 3 1 2 3 3 2 3 6 : 35572
aida11 : 23 13 8 3 3 4 3 3 2 3 6 : 36196
aida12 : 19 7 4 3 2 3 2 3 3 3 6 : 36644
|
