11.05 All system wide checks OK *except* WR Base Current Difference aida01 fault 0xc960 : 0xc971 : 17 aida02 fault 0x8bbf : 0x8bd0 : 17 aida03 fault 0xae9e : 0xaeaf : 17 aida04 fault 0x6e3 : 0x6f4 : 17 aida05 fault 0x31a4 : 0x31bd : 25 aida05 : WR status 0x10 aida06 fault 0x22ea : 0x2303 : 25 aida07 fault 0x438f : 0x43a8 : 25 aida08 fault 0x61ed : 0x6206 : 25 aida09 fault 0x1c32 : 0x1c40 : 14 aida10 fault 0x9332 : 0x933f : 13 aida11 fault 0x227b : 0x2288 : 13 aida12 fault 0xb2fc : 0xb309 : 13 White Rabbit error counter test result: Passed 0, Failed 12 Understand the status reports as follows:- Status bit 3 : White Rabbit decoder detected an error in the received data Status bit 2 : Firmware registered WR error, no reload of Timestamp Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR FPGA Base Current Difference aida01 fault 0x0 : 0x1 : 1 aida02 fault 0x0 : 0x3 : 3 aida03 fault 0x0 : 0x1 : 1 aida04 fault 0x0 : 0x2 : 2 aida06 fault 0x0 : 0x2 : 2 aida08 fault 0x0 : 0x1 : 1 aida11 fault 0x0 : 0x3 : 3 aida12 fault 0x0 : 0x3 : 3 FPGA Timestamp error counter test result: Passed 4, Failed 8 If any of these counts are reported as in error The ASIC readout system has detected a timeslip. That is the timestamp read from the time FIFO is not younger than the last Looks like a big WR glitch happened at some point (master in issue?) Memory Returned 0 0 0 0 0 0 0 0 0 0 0 0 Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k aida01 : 26 20 26 15 3 1 3 2 2 3 4 : 27848 aida02 : 25 7 1 4 1 4 2 2 3 3 6 : 36204 aida03 : 30 5 3 3 3 3 1 3 3 3 6 : 36464 aida04 : 5 10 0 5 2 3 1 3 3 3 6 : 36356 aida05 : 34 40 16 13 4 3 3 2 3 3 4 : 29160 aida06 : 16 8 4 2 1 4 1 3 3 3 6 : 36416 aida07 : 28 23 23 10 4 3 2 4 3 4 3 : 27736 aida08 : 26 9 3 3 1 3 1 3 3 3 6 : 36352 aida09 : 54 42 10 17 3 4 3 4 3 3 4 : 30376 aida10 : 17 5 7 4 3 3 3 3 2 3 6 : 35996 aida11 : 19 10 11 2 1 1 2 4 2 3 6 : 35916 aida12 : 82 42 12 7 4 2 3 2 2 3 4 : 27960 Options unchanged from ELOG 284 DAQ continues OK but New Merger window has disappeared... clearly still running in background! DSSSD leakage currents decreasing as expected - Plan later today: Prepare AIDA Kapton Cables for triple install 4 new FEE64s into S4 (13,14,15,16) Proposed layout of FEE64s (perspective with beam) in fig 5 Cards 9-12 will be moved on Friday when triple is installed When ready MAC addressed will be given to OH/TD who will do the PC configuration including: - Network IP allocation - MIDAS registration - Firmware updating - Checks 17.20: The four new FEEs have been installed and connected to Ethernet, Power, HDMI and Water No front-end adapter is connected yet The MAC addresss are as follows aida13 xilinx_lltemac 81c00000.ethernet: MAC address is now d8:80:39:42: d:15 aida14 xilinx_lltemac 81c00000.ethernet: MAC address is now d8:80:39:42: d: b aida15 xilinx_lltemac 81c00000.ethernet: MAC address is now d8:80:39:41:ee:10 aida16 xilinx_lltemac 81c00000.ethernet: MAC address is now d8:80:39:41:f6:ed
