02:00 System check
The ucesb has stopped around 00:26, the team in the lab ask us to restart AIDA! Called OH for this but the team in the lab figured out thats no need to restart AIDA!
The rates on ucesb got back to work by around 01:12
Deat Time check ok R14_870, attachment 1
Statistics are ok attachment 2
Temperatures are ok attacment 3
Voltages are ok attachment 4
system wide check
All ok except
ADC calibration all failed
FEE64 module aida01 failed
FEE64 module aida02 failed
FEE64 module aida03 failed
FEE64 module aida04 failed
FEE64 module aida05 failed
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida08 failed
FEE64 module aida09 failed
FEE64 module aida10 failed
FEE64 module aida11 failed
FEE64 module aida12 failed
FEE64 module aida13 failed
FEE64 module aida14 failed
FEE64 module aida15 failed
FEE64 module aida16 failed
Calibration test result: Passed 0, Failed 16
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
White rabbite
1 failed
Base Current Difference
aida05 fault 0x500 : 0x569 : 105
White Rabbit error counter test result: Passed 15, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
memory information
Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 20 8 8 5 0 6 1 2 2 2 7 : 37296
aida02 : 19 8 11 2 3 4 2 2 3 3 6 : 36412
aida03 : 14 6 3 4 1 3 1 3 3 3 6 : 36312
aida04 : 25 12 12 4 3 4 1 4 3 3 6 : 37316
aida05 : 4 8 3 4 1 2 2 4 3 3 6 : 36928
aida06 : 42 12 8 7 2 3 3 4 3 3 6 : 37736
aida07 : 24 6 7 3 3 3 1 3 2 2 7 : 37536
aida08 : 10 15 7 2 1 4 2 3 3 3 6 : 36752
aida09 : 29 13 6 6 4 3 3 3 3 3 6 : 37244
aida10 : 18 12 7 2 2 3 3 2 2 4 6 : 37464
aida11 : 20 8 0 5 5 4 2 3 3 3 6 : 36976
aida12 : 7 2 4 3 2 3 2 2 4 3 6 : 37068
aida13 : 2 5 5 4 2 3 2 3 3 3 6 : 36608
aida14 : 9 13 8 2 2 2 3 3 2 4 6 : 37836
aida15 : 24 12 12 1 0 3 2 3 3 3 6 : 36640
aida16 : 12 9 9 2 1 3 2 4 3 3 6 : 37128
6:45 System check
Temperatures, Voltages, Histograms, Statistics, dead time are all ok attachments 5, 6, 7, 8, 9
System wide check are all ok except:
ADC calibration all failed
FEE64 module aida01 failed
FEE64 module aida02 failed
FEE64 module aida03 failed
FEE64 module aida04 failed
FEE64 module aida05 failed
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida08 failed
FEE64 module aida09 failed
FEE64 module aida10 failed
FEE64 module aida11 failed
FEE64 module aida12 failed
FEE64 module aida13 failed
FEE64 module aida14 failed
FEE64 module aida15 failed
FEE64 module aida16 failed
Calibration test result: Passed 0, Failed 16
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
White rabbit 1 failed
Base Current Difference
aida05 fault 0x500 : 0x569 : 105
White Rabbit error counter test result: Passed 15, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
memory information
Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 20 11 3 5 0 6 1 2 3 2 7 : 38264
aida02 : 14 9 9 2 3 3 3 2 3 3 6 : 36496
aida03 : 13 7 3 5 2 3 2 3 3 3 6 : 36668
aida04 : 30 15 13 4 3 4 1 3 4 3 6 : 37888
aida05 : 17 9 3 3 1 2 2 4 3 3 6 : 36956
aida06 : 40 16 5 6 2 3 2 3 2 4 6 : 37936
aida07 : 3 2 3 2 3 4 2 2 2 2 7 : 37196
aida08 : 17 10 6 2 1 3 3 3 3 3 6 : 36852
aida09 : 29 11 7 6 3 3 2 4 3 3 6 : 37436
aida10 : 1 10 5 1 1 3 3 2 2 4 6 : 37252
aida11 : 30 9 0 5 4 4 2 3 3 3 6 : 36960
aida12 : 19 10 5 3 2 3 2 2 4 3 6 : 37196
aida13 : 22 9 6 3 2 3 3 3 3 3 6 : 36960
aida14 : 19 6 9 2 2 3 3 2 2 4 6 : 37452
aida15 : 6 8 11 2 1 3 2 3 3 3 6 : 36616
aida16 : 19 14 5 3 1 3 1 4 3 3 6 : 36908
07:33 system check
Deat time, voltages, statistics, temeratuers are all ok, attachment 10, 11, 12, 13
System wide check
all ok except
ADC all failed
White rabbit
1 failed
Base Current Difference
aida05 fault 0x500 : 0x569 : 105
White Rabbit error counter test result: Passed 15, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
memory information
Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 22 9 4 6 0 5 1 2 2 2 7 : 37152
aida02 : 19 6 13 1 3 3 4 2 3 3 6 : 36780
aida03 : 23 5 6 4 2 3 1 3 3 3 6 : 36452
aida04 : 24 11 14 3 3 4 2 3 3 3 6 : 37048
aida05 : 17 3 6 3 1 2 2 3 3 3 6 : 36444
aida06 : 36 15 4 9 2 4 2 4 3 3 6 : 37608
aida07 : 20 8 5 3 3 4 2 2 2 2 7 : 37376
aida08 : 21 11 10 2 1 4 2 2 2 4 6 : 37324
aida09 : 27 14 7 6 3 3 2 4 3 3 6 : 37452
aida10 : 25 9 5 2 2 3 3 2 2 4 6 : 37436
aida11 : 30 14 2 4 5 3 2 3 3 3 6 : 36936
aida12 : 22 3 5 3 2 3 2 3 3 3 6 : 36640
aida13 : 10 7 1 4 2 3 3 2 3 3 6 : 36336
aida14 : 13 9 12 2 3 3 2 3 2 4 6 : 37820
aida15 : 20 8 11 3 0 3 2 3 3 3 6 : 36640
aida16 : 23 6 6 2 0 2 1 3 4 3 6 : 37164
|
