Entry time:
Wed Jun 16 18:05:03 2021
Author
*
:
Subject
*
:
19.04 All system wide checks OK *except* Base Current Difference aida01 fault 0x8944 : 0x8960 : 28 aida02 fault 0x9b36 : 0x9b52 : 28 aida03 fault 0xf26b : 0xf287 : 28 aida04 fault 0x57a0 : 0x57bc : 28 aida05 fault 0x4d3c : 0x4d55 : 25 aida05 : WR status 0x10 aida06 fault 0x640c : 0x6425 : 25 aida07 fault 0x255e : 0x2577 : 25 aida08 fault 0xffbd : 0xffd6 : 25 aida09 fault 0x87e : 0x895 : 23 aida10 fault 0xc557 : 0xc56e : 23 aida11 fault 0x683e : 0x6855 : 23 aida12 fault 0x1c35 : 0x1c4c : 23 aida13 fault 0x8f41 : 0x8f58 : 23 aida14 fault 0x1b47 : 0x1b5e : 23 aida15 fault 0x4e4 : 0x127e : 3482 aida16 fault 0xf570 : 0xf587 : 23 White Rabbit error counter test result: Passed 0, Failed 16 Base Current Difference aida01 fault 0x0 : 0x2 : 2 aida02 fault 0x0 : 0x2 : 2 aida05 fault 0x0 : 0x2 : 2 aida06 fault 0x0 : 0x2 : 2 aida09 fault 0x0 : 0x2 : 2 aida10 fault 0x0 : 0x2 : 2 aida11 fault 0x0 : 0x2 : 2 aida12 fault 0x0 : 0x3e03 : 15875 aida13 fault 0x0 : 0x32d4 : 13012 aida14 fault 0x0 : 0x2 : 2 aida15 fault 0x0 : 0x2 : 2 aida16 fault 0x0 : 0x2 : 2 FPGA Timestamp error counter test result: Passed 4, Failed 12 If any of these counts are reported as in error The ASIC readout system has detected a timeslip. That is the timestamp read from the time FIFO is not younger than the last Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k aida01 : 53 10 4 4 4 4 2 2 3 3 6 : 36580 aida02 : 28 7 10 4 3 4 3 2 2 4 6 : 37768 aida03 : 41 10 7 6 5 3 1 3 3 3 6 : 36836 aida04 : 45 7 2 4 3 4 2 3 3 3 6 : 36940 aida05 : 35 8 8 4 4 4 2 2 2 4 6 : 37580 aida06 : 45 6 6 3 3 3 2 3 4 3 6 : 37860 aida07 : 37 10 6 4 5 2 3 2 2 4 6 : 37636 aida08 : 32 5 10 4 4 4 3 2 2 4 6 : 37832 aida09 : 24 5 8 7 1 3 3 2 2 4 6 : 37544 aida10 : 29 9 12 5 4 3 3 3 3 3 6 : 37276 aida11 : 33 7 7 6 3 4 3 3 1 4 6 : 37292 aida12 : 36 11 6 6 3 4 3 3 1 4 6 : 37320 aida13 : 37 7 6 6 5 3 3 3 1 4 6 : 37292 aida14 : 25 9 7 6 5 3 3 3 3 3 6 : 37276 aida15 : 3 3 4 3 0 3 3 2 1 4 7 : 40260 aida16 : 35 7 6 6 4 4 3 3 1 4 6 : 37348 Collecting the file size of each FEE64 Options CONTENTS file to check they are all the same FEE : aida01 => Options file size is 1026 Last changed Sat Jun 12 15:46:33 CEST 2021 FEE : aida02 => Options file size is 1025 Last changed Sun May 23 00:19:21 CEST 2021 FEE : aida03 => Options file size is 1014 Last changed Thu Apr 29 14:43:50 CEST 2021 FEE : aida04 => Options file size is 1025 Last changed Fri May 14 16:54:56 CEST 2021 FEE : aida05 => Options file size is 1025 Last changed Mon May 17 06:25:41 CEST 2021 FEE : aida06 => Options file size is 1014 Last changed Thu Apr 29 14:43:59 CEST 2021 FEE : aida07 => Options file size is 1014 Last changed Thu Apr 29 14:44:02 CEST 2021 FEE : aida08 => Options file size is 1025 Last changed Sun May 23 00:16:54 CEST 2021 FEE : aida09 => Options file size is 1014 Last changed Thu Apr 29 14:44:08 CEST 2021 FEE : aida10 => Options file size is 1014 Last changed Thu Apr 29 14:44:57 CEST 2021 FEE : aida11 => Options file size is 1014 Last changed Thu Apr 29 14:44:57 CEST 2021 FEE : aida12 => Options file size is 1014 Last changed Thu Apr 29 14:44:57 CEST 2021 FEE : aida13 => Options file size is 1025 Last changed Fri May 07 19:40:34 CEST 2021 FEE : aida14 => Options file size is 1014 Last changed Thu Apr 29 14:44:57 CEST 2021 FEE : aida15 => Options file size is 1025 Last changed Sat Jun 12 15:48:28 CEST 2021 FEE : aida16 => Options file size is 1014 Last changed Thu Apr 29 14:44:57 CEST 2021 19.07 Hot HEC channels - ASIC check Grafana - DSSSD bias & leakage current - most recent 7 days - attachment 1 Lost activity monitor - attachment 2 1.8.W spectra - 20us FSR - attachments 3 & 4 ADC data items - attachment 5 FEE64 temperatures OK - attachment 6 DSSSD bias & leakage currents - attachment 7 significant increases of leakage current to c. 12uA - temperature c. 30 deg C Merger/Tape Server/Merger statistics - attachment 8 no merger errors reported since previous restart
