Entry time:
Wed Nov 15 01:02:59 2017
Author
*
:
Subject
*
:
Header: Continue with 5.0 MeV/ Ender: ==================================================== Run number : 151 Date : 15 / 11 / 2017 Start time : 02:03:26 Stop time : 04:19:06 Trigger rate (MIDAS) : 5 Blocks written : 577 —————————————————————————————— Run Scalers (approx rates) 0- Ungated : 5 1- Gated : 4 2- dE : 62k 3- E : 128 4- HI : 495 5- Pulser : 1 6- Clock : 969 —————————————————————————————— Beam energy (MeV/u) : 5.0 MeV/u (nominal) Beam intensity (epA) : 2.25 Target : CH2_33+10+01 Ladder position (mm) : 97.61 HI Degrader foil (um) : 15 um Al —————————————————————————————— del_E voltage (V) : -40 del_E leakage (uA) : 0.66 E voltage (V) : -350 E leakage (uA) : 2.065 E_hi voltage (V) : -14 E_hi leakage (uA) : 3.265 —————————————————————————————— PA power (Up, positive) (A) : 1.55 PA power (Up, negative) (A) : 0.59 PA power (Down, positive) (A) : 0.8 PA power (Down, negative) (A) : 0.28 —————————————————————————————— Pressure (IMG1) (mbar) : 8.2 x 10^-6 Pressure (old gauge) (mbar) : 2.2 x 10^-5 Pressure (SEC) (mbar) : 5.0 x 10^-6 —————————————————————————————— Temp (Chiller) deg : -9.9 Temp (chamber) deg : 5.8 —————————————————————————————— Comments: Proton beam intensity dropped briefly, from 2:50 to 3:00 AM (drop was about ~5 min). Normal value was 1.5 uA, dropped down to 0.5 uA before recovered. ====================================================
Encoding
:
HTML
ELCode
plain
Suppress Email notification
Resubmit as new entry
Attachment 1:
Original size: 2049x1417
