Entry time:
Thu Nov 9 03:32:55 2017
Author
*
:
Subject
*
:
Header: Continue 5.0 MeV/u with CH2 after target re-heating Ender: End ==================================================== Run number : 55 Date : 9 Nov 2017 Start time : 04:32 Stop time : 06:34 Trigger rate (MIDAS) : 2081 Blocks written : 16180 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Beam energy : 5.0 MeV/u Beam intensity : ~2 epA -> (2*10^-12)/(24*1.602*10^-19) = 520833 pps NB: See https://elog.ph.ed.ac.uk/ISOLDE/54 for factor 24 rather than 20 (theoretical estimate) Target : #2 CH2_16 (450~480 ug/cm^2) Ladder position : 127.95 mm HI Degrader foil (um) : 15 um Al 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 del_E voltage (V) : -32 V del_E leakage (uA) : 0.02 uA E voltage (V) : -350 V E leakage (uA) : 1.75 uA E_hi voltage (V) : -14 V E_hi leakage (uA) : 0.82 uA 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 PA power (upstream, positive) : 1.52 A PA power (upstream, negative) : 0.55 A PA power (downstream, positive) : 0.8 A PA power (downstream, negative) : 0.32 A 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Pressure (IMG1) : 7.5 x 10^-6 mbar Pressure (old gauge) : 2.3 x 10^-5 mbar Pressure (SEC) : 4.0 x 10^-6 mbar 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Temp (Chiller) : -10.0 deg Temp (chamber) : +5.4 deg 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Comments: First laser does not have a red peak at the center, but maybe okay for this shift. Attaching PSB and GPS screenshots, as we need to monitor them regularly. At 6:18 to 6:40, we started getting four rings from the PS Booster. The 1st ring had a fairly low intensity, and the operators later dropped it. These times were confirmed exactly with communication with PS operators. again. ====================================================
