Entry time:
Fri Nov 10 07:00:14 2017
Author
*
:
Subject
*
:
Header: 4.7 MeV/u and CH2_30+25. Ender: beam stop at PS (6 hour interruption) ==================================================== Run number : 80 Date : 10/11 Start time : 08:00:49 Stop time : 08:35:05 Trigger rate (MIDAS) : 8 Blocks written : 202 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Run Scalars (approx rates) 0- Ungated : 9 1- Gated : 8 2- dE : 42 3- E : 8 4- HI : 482 5- Pulser : 2 6- Clock : 967 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Beam energy : 4.7 MeV/u Beam intensity : not checked this run (should be around 1.5pA) Target : CH2_30+25 (Pos#6; 490-520 ug/cm2) Ladder position : 67.26 HI Degrader foil (um) : 15 um Al 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 del_E voltage (V) : -32 del_E leakage (uA) : 0.8 E voltage (V) : -350 E leakage (uA) : 1.745 E_hi voltage (V) : -13.5 to -14 E_hi leakage (uA) : 0.905 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 PA power (upstream, positive) : 1.55 A PA power (upstream, negative) : -0.55 A PA power (downstream, positive) : 0.8 A PA power (downstream, negative) : -0.28 A 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Pressure (IMG1) : 6.75E-06 Pressure (old gauge) : 1.9E-05 Pressure (SEC) : 3.9E-06 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Temp (Chiller) : -10.0 Temp (chamber) : 5.5 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Comments: - since 6:20 RF problem on ring2 (although 3 full inj are shown) : ~1.6E+14 protons only - 8.21 comment on PS: 6 hours of no beam - 08:35 stop run, because no beam ====================================================
Encoding
:
HTML
ELCode
plain
Suppress Email notification
Resubmit as new entry
Attachment 1:
Original size: 831x598
Attachment 2:
Original size: 830x597
Attachment 3:
