Entry time:
Sat Nov 11 06:57:14 2017
Author
*
:
Subject
*
:
Header: 3.99 MeV/u and CH2_30+25. Continue after Laser update (cleaning), but still no real beam Ender: ==================================================== Run number : 89 Date : 11/11/17 Start time : 07:57:31 Stop time : 08:31:57 Trigger rate (MIDAS) : 0 Blocks written : 1 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Run Scalars (approx rates) 0- Ungated : 1- Gated : 2- dE : 3- E : 4- HI : 5- Pulser : 6- Clock : 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Beam energy (MeV/u) : 3.99 MeV/u Beam intensity (epA) : 0.05 - 0.1 pA Target : CH2_30+25 (Pos#6; 490-520 ug/cm2) Ladder position (mm) : 67.26 HI Degrader foil (um) : 10 um Al 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 del_E voltage (V) : -40 del_E leakage (uA) : 0.65 E voltage (V) : -350 E leakage (uA) : 2.11 E_hi voltage (V) : -14 E_hi leakage (uA) : 2.42 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 PA power (Up, positive) (A) : 1.55 PA power (Up, negative) (A) : -0.55 PA power (Down, positive) (A) : 0.8 PA power (Down, negative) (A) : -0.28 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Pressure (IMG1) (mbar) : 7.65 E-06 Pressure (old gauge) (mbar) : 2.2 E-05 Pressure (SEC) (mbar) : 4.3 E-06 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Temp (Chiller) deg : -10.1 Temp (chamber) deg : 5.6 覧覧覧覧覧覧覧覧覧覧覧覧覧覧覧 Comments: 8 good event in first 8 minutes then laser was optimized, but still 0.1pA beam (almost nothing), called Miguel and he fixed it remotely Beam back at 08:28:20, so the last 3 minutes there was some beam. Stopped to start a new run. ====================================================
