02:01 Beam has stopped at 01:37 and returend at 01:43 for few min and then stopped again and not knowen how it will take until it is back
AIDA scalers attached 1
statistic attached 2
temretuer attached 3
bias attached 4
Clock check ok
ADC check :
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida10 failed
Calibration test result: Passed 9, Failed 3
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0x1a52 : 0x1a55 : 3
aida06 fault 0x4f3e : 0x4f41 : 3
aida07 fault 0x3bcd : 0x3bea : 29
aida08 fault 0xc7c7 : 0xc7ca : 3
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Base Current Difference
aida09 fault 0x0 : 0x1 : 1
aida12 fault 0x0 : 0x9 : 9
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 32 8 3 1 0 3 1 3 3 3 6 : 36240
aida02 : 11 7 9 3 1 2 2 4 2 3 6 : 35988
aida03 : 32 4 13 5 5 4 3 3 2 3 6 : 36432
aida04 : 26 7 6 1 2 3 2 4 2 3 6 : 36128
aida05 : 18 8 8 7 4 2 2 2 2 4 6 : 37352
aida06 : 24 11 3 1 2 5 1 3 3 3 6 : 36616
aida07 : 14 5 3 3 3 2 3 2 4 3 6 : 37296
aida08 : 21 7 1 5 0 1 2 3 3 3 6 : 36284
aida09 : 0 7 1 1 1 3 2 2 3 3 6 : 35880
aida10 : 22 5 3 4 1 2 2 2 3 3 6 : 35952
aida11 : 4 3 1 1 2 2 3 3 2 3 6 : 35544
aida12 : 22 10 5 4 4 4 1 3 3 3 6 : 36728
02:19 beam is back
03:58 The beam has not been stable yet
The rate reach 1.5 kHz, they will contact FRS team to lower the intensity of the beam
AIDA scalers attached 8
statistic attached 7
temretuer attached 6
bias attached 5
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida10 failed
Calibration test result: Passed 9, Failed 3
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0x1a52 : 0x1a55 : 3
aida06 fault 0x4f3e : 0x4f41 : 3
aida07 fault 0x3bcd : 0x3beb : 30
aida08 fault 0xc7c7 : 0xc7ca : 3
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Base Current Difference
aida09 fault 0x0 : 0x1 : 1
aida12 fault 0x0 : 0x9 : 9
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 21 8 6 2 1 2 1 3 3 3 6 : 36212
aida02 : 24 14 14 2 1 2 2 4 2 3 6 : 36144
aida03 : 31 5 10 5 5 4 2 3 2 3 6 : 36132
aida04 : 12 11 12 2 2 2 3 4 2 3 6 : 36360
aida05 : 23 8 5 7 4 2 2 2 2 4 6 : 37324
aida06 : 21 14 14 1 3 5 1 3 3 3 6 : 36868
aida07 : 15 9 5 0 3 2 3 2 4 3 6 : 37268
aida08 : 21 11 10 3 0 1 2 3 3 3 6 : 36396
aida09 : 5 7 5 1 1 3 1 3 3 3 6 : 36220
aida10 : 15 13 12 3 2 1 2 2 3 3 6 : 36036
aida11 : 13 10 1 0 2 2 2 4 2 3 6 : 35860
aida12 : 29 5 4 5 5 3 1 3 3 3 6 : 36668
05: 07 The rate was a bout 1500 and 2000, we contacted Oscar he said (if it's just bursts it should be ok), so they decided to do nothing.
06:26
AIDA scalers attached 9
statistic attached 10
temretuer attached 11
bias attached 12
Clock status test result: Passed 12, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida10 failed
Calibration test result: Passed 9, Failed 3
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida01 fault 0x7685 : 0x7686 : 1
aida02 fault 0x941c : 0x941d : 1
aida03 fault 0x7cd6 : 0x7cd7 : 1
aida04 fault 0xb86c : 0xb86d : 1
aida05 fault 0x1a52 : 0x1a59 : 7
aida06 fault 0x4f3e : 0x4f45 : 7
aida07 fault 0x3bcd : 0x3bf9 : 44
aida08 fault 0xc7c7 : 0xc7ce : 7
aida09 fault 0xb33a : 0xb33b : 1
White Rabbit error counter test result: Passed 3, Failed 9
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Base Current Difference
aida09 fault 0x0 : 0x1 : 1
aida12 fault 0x0 : 0xa : 10
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 17 12 6 2 1 2 1 3 3 3 6 : 36228
aida02 : 19 11 12 3 2 2 2 4 2 3 6 : 36164
aida03 : 25 8 12 5 4 4 3 3 2 3 6 : 36356
aida04 : 22 19 11 3 1 2 3 4 2 3 6 : 36416
aida05 : 35 6 5 6 3 2 2 2 3 3 6 : 36236
aida06 : 12 11 11 2 3 4 1 3 3 3 6 : 36664
aida07 : 18 6 2 1 3 2 3 2 3 3 6 : 36216
aida08 : 27 10 8 3 0 1 2 3 3 3 6 : 36380
aida09 : 18 6 6 1 0 2 2 2 3 3 6 : 35832
aida10 : 3 14 10 3 1 1 2 3 3 3 6 : 36412
aida11 : 1 3 2 0 2 2 2 4 2 3 6 : 35772
aida12 : 0 5 6 3 3 4 1 3 3 3 6 : 36520
07:57 The beam stopped and they said there is a water leak !
|
