03:09   General check

Rates, temptature, voltages are OK attached 1, 2, 3, 4

****Clock Ckeck******

OK
Clock status test result: Passed 12, Failed 0

Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable

******ADC check ******
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida10 failed
Calibration test result: Passed 9, Failed 3

If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module

****** White Rabbit check******

     Base         Current     Difference
aida01 fault      0x7686 :      0x768a :      4
aida02 fault      0x941d :      0x9421 :      4
aida03 fault      0x7cd7 :      0x7cdb :      4
aida04 fault      0xb86d :      0xb871 :      4
aida05 fault      0x1a59 :      0x1a61 :      8
aida06 fault      0x4f45 :      0x4f4d :      8
aida07 fault      0x3bfc :      0x3c2c :      48
aida08 fault      0xc7ce :      0xc7d5 :      7
aida09 fault      0xb33b :      0xb33c :      1
White Rabbit error counter test result: Passed 3, Failed 9

Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR

*****FPGA check ******

             Base         Current         Difference
aida09 fault      0x1 :      0x2 :      1
aida12 fault      0xa :      0x10 :      6
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

*****Memory check*****

Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) :    4    8    16    32    64    128    256    512    1k    2k    4k
aida01 :      6     12     11      7      2      3      2      4      2      3      6   : 36360
aida02 :     21     15      7      3      2      3      1      4      2      3      6   : 35996
aida03 :      9     10     10      2      4      3      3      3      2      3      6   : 36052
aida04 :     17     17     17      4      0      2      3      4      2      3      6   : 36444
aida05 :     25      7      3      1      1      1      2      3      2      4      6   : 37292
aida06 :     29     15      7      2      3      4      1      3      3      3      6   : 36700
aida07 :     17     17      6      5      2      3      2      3      3      3      6   : 36812
aida08 :     22      6     10      5      3      1      3      4      2      3      6   : 36360
aida09 :     18     28     14      4      2      3      3      3      2      3      6   : 36232
aida10 :     26     16      4      3      3      1      3      4      2      3      6   : 36296
aida11 :     16     10      4      0      3      3      1      4      2      3      6   : 35856
aida12 :     19     14      4      2      4      4      1      3      3      3      6   : 36668

04:15      General Check

Rates, Tempratures, Voltages are ok, attached 5,6,7,8

******Clock Check*******

OK

Clock status test result: Passed 12, Failed 0

Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable

******ADC******

Clock status test result: Passed 12, Failed 0

Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable

******White Rabbit check******

         Base         Current     Difference
aida01 fault      0x7686 :      0x768a :      4
aida02 fault      0x941d :      0x9421 :      4
aida03 fault      0x7cd7 :      0x7cdb :      4
aida04 fault      0xb86d :      0xb871 :      4
aida05 fault      0x1a59 :      0x1a61 :      8
aida06 fault      0x4f45 :      0x4f4d :      8
aida07 fault      0x3bfc :      0x3c39 :      61
aida08 fault      0xc7ce :      0xc7d5 :      7
aida09 fault      0xb33b :      0xb33c :      1
White Rabbit error counter test result: Passed 3, Failed 9

Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR

******FPGA Check******

     Base         Current         Difference
aida09 fault      0x1 :      0x2 :      1
aida12 fault      0xa :      0x11 :      7
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

****** Memorey check******

Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) :    4    8    16    32    64    128    256    512    1k    2k    4k
aida01 :     27     21     10      7      1      3      2      4      2      3      6   : 36436
aida02 :     28     21      3      3      1      3      1      4      2      3      6   : 35944
aida03 :     15      8     11      3      3      3      3      3      2      3      6   : 36044
aida04 :     25     19     14      4      1      3      4      3      2      3      6   : 36380
aida05 :     12      6      5      1      0      2      2      3      2      4      6   : 37328
aida06 :     29     21      4      2      3      4      1      3      3      3      6   : 36700
aida07 :     19     14      7      6      2      3      2      2      3      3      6   : 36332
aida08 :     11      8      8      6      3      1      3      4      2      3      6   : 36332
aida09 :     16     25     11      3      1      2      2      4      2      3      6   : 36184
aida10 :     14     13      4      2      3      2      2      4      2      3      6   : 36064
aida11 :      4      9      4      0      3      3      1      4      2      3      6   : 35800
aida12 :     38     17      4      2      4      4      1      3      3      3      6   : 36768
