Quick system checks after crash
Temperature ok.
Still cannot connect remotely to /ucesb with my gsi web login and password (?).
Clock status test result: Passed 12, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
Calibration test result: Passed 12, Failed 0
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0x31a2 : 0x31a2 : 0
aida05 : WR status 0x10
White Rabbit error counter test result: Passed 11, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 9 3 4 2 3 2 1 4 2 3 7 : 39804
aida02 : 29 4 2 3 0 3 1 4 2 3 7 : 39828
aida03 : 20 6 1 2 2 3 1 4 2 3 7 : 39888
aida04 : 19 5 4 2 1 3 1 4 2 3 7 : 39860
aida05 : 27 5 4 1 2 3 2 3 1 4 7 : 40692
aida06 : 17 10 3 2 1 3 1 4 2 3 7 : 39876
aida07 : 22 7 2 2 2 3 1 4 2 3 7 : 39920
aida08 : 12 6 5 1 3 2 1 4 2 3 7 : 39824
aida09 : 0 9 1 3 1 3 1 4 2 3 7 : 39800
aida10 : 2 2 2 3 3 2 3 2 2 3 7 : 39256
aida11 : 21 7 4 3 0 3 2 3 2 3 7 : 39596
aida12 : 18 8 3 0 2 3 2 3 2 3 7 : 39608
|
