Wide checks at Time 22:22 CET

Clock status test result: Passed 16, Failed 0

Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable

FEE64 module aida01 failed
FEE64 module aida02 failed
FEE64 module aida03 failed
FEE64 module aida04 failed
FEE64 module aida05 failed
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida08 failed
FEE64 module aida09 failed
FEE64 module aida10 failed
FEE64 module aida11 failed
FEE64 module aida12 failed
FEE64 module aida13 failed
FEE64 module aida14 failed
FEE64 module aida15 failed
FEE64 module aida16 failed
Calibration test result: Passed 0, Failed 16

If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module

         Base         Current     Difference
aida01 fault      0xf932 :      0xf933 :      1
aida02 fault      0x62ec :      0x62ed :      1
aida03 fault      0x8679 :      0x867a :      1
aida04 fault      0xf0e4 :      0xf0e5 :      1
aida05 fault      0x9db8 :      0x9dbc :      4
aida06 fault      0x7f18 :      0x7f19 :      1
aida07 fault      0xdd2c :      0xdd2d :      1
aida08 fault      0x1557 :      0x1558 :      1
White Rabbit error counter test result: Passed 8, Failed 8

Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR

             Base         Current         Difference
aida05 fault      0x0 :      0x2 :      2
FPGA Timestamp error counter test result: Passed 15, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) :    4    8    16    32    64    128    256    512    1k    2k    4k
aida01 :     35     11      3      5      5      4      1      3      2      4      6   : 37876
aida02 :     20      5      4      3      2      5      2      4      3      3      6   : 37400
aida03 :     20      3      4      3      4      4      1      3      2      4      6   : 37640
aida04 :     25      6      2      3      4      4      3      3      3      3      6   : 37140
aida05 :     30     10      5      7      2      6      2      4      2      4      6   : 38776
aida06 :     21     11      4      4      3      5      2      4      3      3      6   : 37548
aida07 :     23      8      4      4      2      6      1      3      2      4      6   : 37852
aida08 :     27      7      2      3      4      3      2      4      3      3      6   : 37284
aida09 :     31      6      5      6      3      3      2      4      3      3      6   : 37372
aida10 :     22      5      3      4      3      6      2      2      2      4      6   : 37616
aida11 :     23      5      4      2      5      2      1      3      2      4      6   : 37444
aida12 :     20      7      4      7      3      5      2      3      3      3      6   : 37096
aida13 :     28      5      3      3      1      5      2      3      3      3      6   : 36840
aida14 :     38     12      2      4      2      4      1      4      3      3      6   : 37144
aida15 :     27      9      5      4      2      5      3      2      3      3      6   : 36740
aida16 :     21      6      4      4      1      4      2      3      3      3      6   : 36740
