System Wide check at begining of the night shift:
-----
Clock status test result: Passed 16, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
-----
ADC calibration:
FEE64 module aida01 failed
FEE64 module aida02 failed
FEE64 module aida03 failed
FEE64 module aida04 failed
FEE64 module aida05 failed
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida08 failed
FEE64 module aida09 failed
FEE64 module aida10 failed
FEE64 module aida11 failed
FEE64 module aida12 failed
FEE64 module aida13 failed
FEE64 module aida14 failed
FEE64 module aida15 failed
FEE64 module aida16 failed
Calibration test result: Passed 0, Failed 16
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
-----
White rabbit status:
Base Current Difference
aida05 fault 0x500 : 0x56d : 109
White Rabbit error counter test result: Passed 15, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
-----
FPGA Timestamp error counter test result: Passed 16, Failed 0
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
-----
Memory info from FEE cards
Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 20 7 7 6 1 5 2 2 3 3 6 : 36472
aida02 : 19 5 4 4 4 3 3 3 2 3 6 : 36020
aida03 : 22 10 2 2 5 2 2 3 3 3 6 : 36680
aida04 : 12 7 1 0 4 3 1 4 3 3 6 : 36856
aida05 : 16 7 5 3 1 3 2 3 3 3 6 : 36584
aida06 : 20 7 5 6 2 4 4 2 3 3 6 : 36888
aida07 : 13 7 5 2 3 2 1 3 2 2 7 : 37308
aida08 : 18 7 5 3 0 2 3 3 3 3 6 : 36656
aida09 : 21 6 4 4 1 4 2 3 3 3 6 : 36740
aida10 : 21 10 2 3 2 3 2 2 2 4 6 : 37156
aida11 : 23 2 4 4 3 2 2 3 2 4 6 : 37612
aida12 : 24 1 4 3 2 2 1 2 4 3 6 : 36744
aida13 : 26 9 4 2 1 4 3 2 3 3 6 : 36464
aida14 : 19 9 9 2 3 4 1 2 2 4 6 : 37156
aida15 : 10 7 10 0 1 3 1 3 3 3 6 : 36288
aida16 : 28 7 3 2 1 3 3 3 3 3 6 : 36824 |
