System wide checks at 7am CET
All seems fine, nothing significant to report
Slight increase of dead time noted in FEE 3, 5 and 7.
-----
Clock status test result: Passed 16, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
-----
ADC calibration
FEE64 module aida01 failed
FEE64 module aida02 failed
FEE64 module aida03 failed
FEE64 module aida04 failed
FEE64 module aida05 failed
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida08 failed
FEE64 module aida09 failed
FEE64 module aida10 failed
FEE64 module aida11 failed
FEE64 module aida12 failed
FEE64 module aida13 failed
FEE64 module aida14 failed
FEE64 module aida15 failed
FEE64 module aida16 failed
Calibration test result: Passed 0, Failed 16
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
-----
White Rabbit:
Base Current Difference
aida05 fault 0x500 : 0x56e : 110
White Rabbit error counter test result: Passed 15, Failed 1
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
-----
FPGA Timestamp error counter test result: Passed 16, Failed 0
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
-----
Returned 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 23 5 6 5 0 4 1 3 3 3 6 : 36484
aida02 : 10 3 3 2 3 2 2 2 3 3 6 : 35952
aida03 : 2 5 1 4 5 2 2 3 3 3 6 : 36608
aida04 : 1 3 4 0 4 3 2 3 3 3 6 : 36572
aida05 : 19 9 3 2 2 3 1 3 4 3 6 : 37380
aida06 : 13 11 1 5 3 4 4 2 3 3 6 : 36860
aida07 : 12 2 4 3 3 2 1 3 2 2 7 : 37280
aida08 : 25 5 7 1 1 3 3 3 3 3 6 : 36828
aida09 : 22 5 6 4 1 3 2 3 3 3 6 : 36640
aida10 : 23 8 6 3 2 3 2 2 2 4 6 : 37212
aida11 : 24 14 7 3 3 2 3 3 3 3 6 : 36960
aida12 : 16 10 5 3 1 2 1 2 4 3 6 : 36736
aida13 : 23 6 4 2 2 3 2 3 3 3 6 : 36620
aida14 : 22 7 8 4 3 4 1 2 2 4 6 : 37200
aida15 : 10 12 9 2 1 3 1 3 3 3 6 : 36376
aida16 : 18 5 6 2 0 3 2 4 3 3 6 : 37008
|
