Clock status test result: Passed 12, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
Calibration test result: Passed 12, Failed 0
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0xc879 : 0xc87b : 2
aida06 fault 0x323c : 0x323e : 2
aida07 fault 0xfb3a : 0xfb3f : 5
aida08 fault 0xd3d6 : 0xd3d8 : 2
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
FPGA Timestamp error counter test result: Passed 12, Failed 0
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 23 10 3 1 1 2 1 3 3 3 6 : 36156
aida02 : 25 10 4 3 1 2 2 3 3 3 6 : 36500
aida03 : 27 8 5 2 3 4 3 3 2 3 6 : 36092
aida04 : 30 4 4 5 0 2 4 2 3 3 6 : 36472
aida05 : 19 5 7 1 3 2 2 2 2 4 6 : 37060
aida06 : 18 13 1 2 1 3 2 3 3 3 6 : 36544
aida07 : 24 7 3 2 2 3 1 3 2 4 6 : 37384
aida08 : 15 11 2 5 2 4 1 4 3 3 6 : 37076
aida09 : 7 3 4 1 5 6 5 4 3 2 6 : 36308
aida10 : 8 3 13 4 3 3 1 4 2 3 6 : 36040
aida11 : 18 11 17 7 4 4 4 3 2 3 6 : 36752
aida12 : 12 7 7 7 4 4 2 3 2 3 6 : 36024
Collecting the file size of each FEE64 Options CONTENTS file to check they are all the same
FEE : aida01 => Options file size is 1025 Last changed Fri Apr 16 01:00:12 CEST 2021
FEE : aida02 => Options file size is 1014 Last changed Fri Apr 16 00:56:20 CEST 2021
FEE : aida03 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida04 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida05 => Options file size is 1025 Last changed Fri Apr 16 00:53:25 CEST 2021
FEE : aida06 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida07 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida08 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida09 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida10 => Options file size is 1014 Last changed Wed Apr 14 21:52:06 CEST 2021
FEE : aida11 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida12 => Options file size is 1025 Last changed Wed Apr 14 21:58:54 CEST 2021
17:27. Checked system stats, temps, leakage etc. looks ok
18:49. Tape server writing to disk /NULL/R21_9+
/TapeData points to /media/SecondDrive/ - 3.6Tb free
19.15. checks
Clock status test result: Passed 12, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
Calibration test result: Passed 12, Failed 0
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0xc879 : 0xc87b : 2
aida06 fault 0x323c : 0x323e : 2
aida07 fault 0xfb3a : 0xfb3f : 5
aida08 fault 0xd3d6 : 0xd3d8 : 2
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Base Current Difference
aida07 fault 0xf : 0x10 : 1
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 16 9 16 2 2 2 1 3 3 3 6 : 36424
aida02 : 1 3 5 4 1 3 3 2 3 3 6 : 36268
aida03 : 24 13 11 6 3 3 2 4 2 3 6 : 36472
aida04 : 5 4 4 4 3 3 3 2 3 3 6 : 36404
aida05 : 17 8 4 2 2 2 2 2 2 4 6 : 36996
aida06 : 26 11 3 2 0 3 2 3 3 3 6 : 36528
aida07 : 24 7 2 1 1 1 2 3 2 4 6 : 37272
aida08 : 13 12 6 3 3 4 1 4 3 3 6 : 37140
aida09 : 22 15 19 2 6 5 4 4 3 2 6 : 36416
aida10 : 16 11 6 4 3 3 1 4 2 3 6 : 36024
aida11 : 12 4 5 4 2 3 3 3 2 3 6 : 35872
aida12 : 18 12 9 4 4 4 2 3 2 3 6 : 36024
Collecting the file size of each FEE64 Options CONTENTS file to check they are all the same
FEE : aida01 => Options file size is 1025 Last changed Fri Apr 16 01:00:12 CEST 2021
FEE : aida02 => Options file size is 1014 Last changed Fri Apr 16 00:56:20 CEST 2021
FEE : aida03 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida04 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida05 => Options file size is 1025 Last changed Fri Apr 16 00:53:25 CEST 2021
FEE : aida06 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida07 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida08 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida09 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida10 => Options file size is 1014 Last changed Wed Apr 14 21:52:06 CEST 2021
FEE : aida11 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida12 => Options file size is 1025 Last changed Wed Apr 14 21:58:54 CEST 2021
19.53. Checked system stats, temps, leakage etc. looks ok
20:30. Checked system stats, temps, leakage etc. looks ok
20:59. Checked system stats, temps, leakage etc. looks ok
21:31 System checks
Clock status test result: Passed 12, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
Calibration test result: Passed 12, Failed 0
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0xc879 : 0xc87b : 2
aida06 fault 0x323c : 0x323e : 2
aida07 fault 0xfb3a : 0xfb40 : 6
aida08 fault 0xd3d6 : 0xd3d8 : 2
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Base Current Difference
aida07 fault 0xf : 0x10 : 1
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 21 9 17 3 2 2 1 3 3 3 6 : 36492
aida02 : 5 1 1 6 0 2 2 3 3 3 6 : 36332
aida03 : 2 10 11 6 4 4 3 3 2 3 6 : 36296
aida04 : 27 12 3 4 0 2 3 2 3 3 6 : 36220
aida05 : 19 9 7 2 1 2 2 2 2 4 6 : 36996
aida06 : 28 5 0 4 0 3 1 3 3 3 6 : 36248
aida07 : 19 13 10 6 2 2 1 3 2 4 6 : 37524
aida08 : 18 9 6 0 1 4 1 3 3 3 6 : 36400
aida09 : 17 19 12 3 6 5 4 4 3 2 6 : 36348
aida10 : 23 9 7 4 2 3 1 4 2 3 6 : 35988
aida11 : 19 10 3 3 2 3 3 3 2 3 6 : 35884
aida12 : 12 6 0 3 2 4 2 3 2 3 6 : 35648
Collecting the file size of each FEE64 Options CONTENTS file to check they are all the same
FEE : aida01 => Options file size is 1025 Last changed Fri Apr 16 01:00:12 CEST 2021
FEE : aida02 => Options file size is 1014 Last changed Fri Apr 16 00:56:20 CEST 2021
FEE : aida03 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida04 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida05 => Options file size is 1025 Last changed Fri Apr 16 00:53:25 CEST 2021
FEE : aida06 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida07 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida08 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida09 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida10 => Options file size is 1014 Last changed Wed Apr 14 21:52:06 CEST 2021
FEE : aida11 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida12 => Options file size is 1025 Last changed Wed Apr 14 21:58:54 CEST 2021
22.06. Checked system stats, temps, leakage etc. looks ok
22.18CEST BNC PB-5 amplitude changed from 1V to 2V
fioler NULL/R21_67
22.23CEST All histograms zero'd
22.43. Checked system stats, temps, leakage etc. looks ok
23.21. Checked system stats, temps, leakage etc. looks ok
23.46 system checks
Clock status test result: Passed 12, Failed 0
Understand status as follows
Status bit 3 : firmware PLL that creates clocks from external clock not locked
Status bit 2 : always logic '1'
Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
If all these bits are not set then the operation of the firmware is unreliable
Calibration test result: Passed 12, Failed 0
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
Base Current Difference
aida05 fault 0xc879 : 0xc87b : 2
aida06 fault 0x323c : 0x323e : 2
aida07 fault 0xfb3a : 0xfb40 : 6
aida08 fault 0xd3d6 : 0xd3d8 : 2
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
Base Current Difference
aida07 fault 0xf : 0x10 : 1
FPGA Timestamp error counter test result: Passed 11, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
Returned 0 0 0 0 0 0 0 0 0 0 0 0
Mem(KB) : 4 8 16 32 64 128 256 512 1k 2k 4k
aida01 : 17 12 7 0 3 3 2 4 2 3 6 : 36180
aida02 : 35 3 5 2 0 2 1 3 3 3 6 : 36148
aida03 : 22 6 10 2 1 3 2 4 2 3 6 : 36136
aida04 : 27 9 3 5 2 4 3 3 2 3 6 : 36100
aida05 : 20 9 3 3 2 2 2 2 2 4 6 : 37032
aida06 : 25 11 1 2 0 3 1 3 3 3 6 : 36236
aida07 : 20 6 6 2 3 3 2 4 1 4 6 : 37216
aida08 : 25 10 0 2 1 3 1 3 3 3 6 : 36276
aida09 : 10 4 3 4 4 5 4 4 3 2 6 : 35960
aida10 : 26 9 3 0 1 3 1 4 2 3 6 : 35744
aida11 : 2 3 4 2 2 3 3 3 2 3 6 : 35744
aida12 : 4 9 7 2 2 4 2 3 2 3 6 : 35720
Collecting the file size of each FEE64 Options CONTENTS file to check they are all the same
FEE : aida01 => Options file size is 1025 Last changed Fri Apr 16 01:00:12 CEST 2021
FEE : aida02 => Options file size is 1014 Last changed Fri Apr 16 00:56:20 CEST 2021
FEE : aida03 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida04 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida05 => Options file size is 1025 Last changed Fri Apr 16 00:53:25 CEST 2021
FEE : aida06 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida07 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida08 => Options file size is 1014 Last changed Wed Apr 14 21:52:04 CEST 2021
FEE : aida09 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida10 => Options file size is 1014 Last changed Wed Apr 14 21:52:06 CEST 2021
FEE : aida11 => Options file size is 1014 Last changed Wed Apr 14 21:52:05 CEST 2021
FEE : aida12 => Options file size is 1025 Last changed Wed Apr 14 21:58:54 CEST 2021 |
