Base Current Difference
aida05 fault 0x1a52 : 0x1a53 : 1
aida06 fault 0x4f3e : 0x4f3f : 1
aida07 fault 0x3bcd : 0x3bce : 1
aida08 fault 0xc7c7 : 0xc7c8 : 1
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
13:55 CEST
Statistics : ok elog:234/4
Temp : ok elog:234/5
Bias : ok elog:234/6
ucesb : ok
DB: No faults found
ADC Calibration check:
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida10 failed
Calibration test result: Passed 9, Failed 3
If any modules fail calibration , check the clock status and open the FADC Align and
Control browser page to rerun calibration for that module
White Rabbit Check:
Base Current Difference
aida05 fault 0x1a52 : 0x1a53 : 1
aida06 fault 0x4f3e : 0x4f3f : 1
aida07 fault 0x3bcd : 0x3bcf : 2
aida08 fault 0xc7c7 : 0xc7c8 : 1
White Rabbit error counter test result: Passed 8, Failed 4
FPGA check:
Base Current Difference
aida09 fault 0x0 : 0x1 : 1
aida12 fault 0x0 : 0x2 : 2
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last
14:05 no beam
14:10 beam back
14:15 no beam, beam current being optimised, going to thicker degrader when beam returns
14:37 CEST
Statistics : ok
Temp : ok
Bias : ok (ch3 now over 6uA)
ucesb : ok
DB: No faults found
15:03 CEST
Statistics : ok
Temp : ok
Bias : ok
ucesb : ok
DB: No faults found
15:31 CEST
Statistics : ok
Temp : ok
Bias : ok
ucesb : ok
DB: No faults found
15:50
Statistics : ok elog:234/7
Temp : ok elog:234/8
Bias : ok elog:234/9
ucesb : ok elog:234/10
DB: No faults found
ADC Calibration check:
FEE64 module aida06 failed
FEE64 module aida07 failed
FEE64 module aida10 failed
Calibration test result: Passed 9, Failed 3
If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module
White Rabbit Check:
Base Current Difference
aida05 fault 0x1a52 : 0x1a53 : 1
aida06 fault 0x4f3e : 0x4f3f : 1
aida07 fault 0x3bcd : 0x3bcf : 2
aida08 fault 0xc7c7 : 0xc7c8 : 1
White Rabbit error counter test result: Passed 8, Failed 4
Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR
FPGA check:
Base Current Difference
aida09 fault 0x0 : 0x1 : 1
aida12 fault 0x0 : 0x2 : 2
FPGA Timestamp error counter test result: Passed 10, Failed 2
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last |
