0:00 Experiment continues to run smoothly. AIDA DAQ has been rather stable. Leakage current has gone up for the past two days in both DSSDs (combination of high-Z and high-intensity beam and external high temperature).

Stats & Temperatures (VIRTEX,PSU, ASICs)  all ok.

At 0:30

Stats ok - Attachment 1

Temp ok - Attachement 2

HV-LC -Attachment 3

At 2:20

Stats ok - Attachment 4

Temp ok - Attachement 5

HV-LC -Attachment 6

Wide Checks:

Clock status test result: Passed 8, Failed 0

    Understand status as follows
    Status bit 3 : firmware PLL that creates clocks from external clock not locked
    Status bit 2 : always logic '1'
    Status bit 1 : LMK3200(2) PLL and clock distribution chip not locked to external clock
    Status bit 0 : LMK3200(1) PLL and clock distribution chip not locked to external clock
    If all these bits are not set then the operation of the firmware is unreliable

ADC Calibration (same as before):

    FEE64 module aida01 failed
    FEE64 module aida02 failed
    FEE64 module aida03 failed
    FEE64 module aida04 failed
    FEE64 module aida05 failed
    FEE64 module aida06 failed
    FEE64 module aida07 failed
    FEE64 module aida08 failed
    Calibration test result: Passed 0, Failed 8

    If any modules fail calibration , check the clock status and open the FADC Align and Control browser page to rerun calibration for that module

WR decoder status:

         Base         Current     Difference
aida07 fault      0xc53d :      0xc5c9 :      140
aida08 fault      0xf1be :      0xf2b2 :      244
White Rabbit error counter test result: Passed 6, Failed 2

Understand the status reports as follows:-
Status bit 3 : White Rabbit decoder detected an error in the received data
Status bit 2 : Firmware registered WR error, no reload of Timestamp
Status bit 0 : White Rabbit decoder reports uncertain of Timestamp information from WR

FPGA timestamp check:
             Base         Current         Difference
aida07 fault      0x2a :      0x41 :      23
FPGA Timestamp error counter test result: Passed 7, Failed 1
If any of these counts are reported as in error
The ASIC readout system has detected a timeslip.
That is the timestamp read from the time FIFO is not younger than the last

At 4:15:

Stats ok - Attachment 7

Temp ok - Attachement 8

HV-LC -Attachment 9

Wide Checks: No change

At 7:15: (no beam since ~6am -> background run)

Stats ok - Attachment 10

Temp ok - Attachement 11

HV-LC -Attachment 12

Wide Checks: No change
